RF Analyzer HFE35C Basic

€489Excluding VAT
0-2 weeks delivery time
Only a few left (1 items)
0-2 weeks delivery time
Product reminder

Enter your e-mail address below and we will notify you when the product is available! Your e-mail address will be stored up to 180 days.

Product Description:

Radio and microwave meters

This is a slim version of HFE35, which normally has 2 antennas: A green logper antenna (0.8-2.7GHz) and a round UBB27 antenna (27-3000GHz).

  • Microwave meter for GSM, 3G (UMTS), 4G, DECT, Microwave, Bluetooth, etc.
  • Sensitivity 0.1 - 1999 µW / m², microwatt per square meter (equivalent to 0.006 - 0.868 V / m, 75-118 dBµV / m)
  • Sound: Volume or modulation can be selected with the switch and volume adjustment available
  • Hear sound examples: Click here
  • With the modulation, e.g. 217Hz for GSM, 100Hz for Dect and 50 Hz for microwave
  • The log periodic antenna is direction sensitive and makes it possible to find the transmitter at 20 degrees
  • Frequency range measuring instruments 27MHz - 2.7GHz, only one directional antenna for 0.8-2.7GHz included
  • Bag K4 included
  • Swedish and english manual

HFE35C Basic is delivered without the UBB27 antenna

Suitable accessories:
Amplifier HV10_27G3 is available as an accessory. Damper DG20_27G3.

Item ID:

Produced by: Wikinggruppen
